Gauges
Precision Gauges
Process
Pressure Gauges
Grade 2A .5% Accuracy - Micro Adjustable Pointer
Heavy Duty StSt Bushed Movement with Overload and Underload Stops
Liquid Fillable Case (4 1/2" Stem Mount Only)
Phenolic, Aluminum, Stainless Steel Cases
316 StSt Tube & Socket is Standard (Brass available on Special Request)
All Ranges available Vacuum through 20,000 PSI
Full Size and Mini Size
Process Connections: Threaded, Flanged, Sanitary, Inline, and More
Materials of Construction: Carbon Steel, Teflon, Stainless Steel, Monel, Hastelloy, etc.
Fill Fluids: Silicone, Halocarbon, FluoroLube, Syltherm, Ethylene Glycol, etc.
Accessories: Capillary Systems, Locking Devices, etc.
1/4% Accuracy Standard (.1% Available on Digital Gauge)
Mirror Dial, Knife Edge Pointer
StSt Case, 316 SS Tube and Socket
Laminated Saftey Glass Lens
Hermetically Sealed
Overlaod and Underload Stops
Vacuum through 15,000 PSI
4 1/2" & 6" Solid Front Process Gauges
Full Size and Mini Size
Process Connections: Threaded, Flanged, Sanitary, Inline, and More
Materials of Construction: Carbon Steel, Teflon, Stainless Steel, Monel, Hastelloy, etc.
Fill Fluids: Silicone, Halocarbon, FluorLube, Syltherm, Ethylene Glycol, etc.
1/4% Accuracy Standard (.1% Available on Digital Gauge)
Mirror Dial, Knife Edge Pointer
StSt Case, 316 SS Tube and Socket
Laminated Saftey Glass Lens
Hermetically Sealed
Overlaod and Underload Stops
Vacuum through 15,000 PSI
Accessories: Capillary Systems, Locking Devices, etc.
Diaphragm Seal Assemblies
1/4% Accuracy Standard (.1% Available on Digital Gauge)
Mirror Dial, Knife Edge Pointer
StSt Case, 316 SS Tube and Socket
Laminated Saftey Glass Lens
Hermetically Sealed
Overlaod and Underload Stops
Vacuum through 15,000 PSI
Test Gauges
Industrial
Pressure Gauges
All Stainless Steel
Dry and Liquid Filled
Dial Sizes: 1 1/2", 2", 2 1/2", 4", & 6"
Connections: 1/8", 1/4", & 1/2" NPT
Mounting: Bottom, Back or Panel mount
316 SS Tube & Socket
All Welded Construction available
Vacuum through 15,000PSI
115D-Heavy Duty
1% Accuracy
Dial Sizes: 4 1/2" & 6"
Bronze Internals
1/4" NPT Bottom Connection
Vacuum through 1,000 PSI wih removable back Flange
SS Case - 4 1/2” Dial
4 1/2" StSt Case, Bronze Internals
1/4" NPT bottom connection
Vacuum through 500 PSI
1% Accuracy
215: - Liquid Filled
Rear Flanged Industrial
4" Dial, 1/4" NPT bottom connection (Other configurations available)
Vacuum through 15,000 PSI
1% Accuracy
![[x]](index_htm_files/close.png "Close")
Liquid Filled
Gauges
201L- Stem Mount
Dial Sizes: 1 1/2", 2", 2 1/2", 4", & 6"
Stainless Steel Case
Bronze Tube and Movement
Brass bottom mount
Glycerine fill, plastic lens
1.5% Accuracy on 2 1/2" & 4" Dial
2% Accuracy on 1 1/2" & 2" Dial
202L - Black Mount
Dial Sizes: 1 1/2", 2", 2 1/2", 3 1/2", & 4"
Stainless Steel Case
Bronze Tube and Movement
Brass back mount
Glycerine fill, plastic lens
1.5% Accuracy on 2 1/2" & 4" Dial
2% Accuracy on 1 1/2" & 2" Dial
203L -U-Clamp Mount
Dial Sizes: 1 1/2", 2", 2 1/2", 3 1/2", & 4"
Stainless Steel Case
Bronze Tube and Movement
Brass back mount, U-Clamp
Glycerine fill, plastic lens
1.5% Accuracy on 2 1/2" & 4" Dial
2% Accuracy on 1 1/2" & 2" Dial
204L - Front Flange Mount
Dial Sizes: 1 1/2", 2", 2 1/2", 3 1/2", & 4"
Stainless Steel Case
Bronze Tube and Movement
Brass bak mount, Front flanged
Glycerine fill, plastic lens
1.5% Accuracy on 2 1/2" & 4" Dial
2% Accuracy on 1 1/2" & 2" Dial
Utility
Gauges
101D-Stem Mount
Dial Sizes: 1 1/2", 2", 2 1/2", 3 1/2", & 4 1/2"
Connections: 1/8" NPT on 1 1/2", & 2", 1/4" NPT on 2", 2 1/2", 3 1/2", 4 1/2"
Black Steel Case, bottom connection
Bronze Tube, Brass Socket
Plastic Lens Standard
Accuracy: 3-2-3%
102D-Back Mount
Dial Sizes: 1 1/2", 2", 2 1/2", 3 1/2"
Connections: 1/8" NPT on 1 1/2", & 2", 1/4" NPT on 2", 2 1/2", 3 1/2"
Black Steel Case, back connection
Bronze Tube, Brass Socket
Plastic Lens Standard
Accuracy: 3-2-3%
103D-U-Clamp Mount
Dial Sizes: 1 1/2", 2", 2 1/2", 3 1/2"
Connections: 1/8" NPT on 1 1/2", & 2", 1/4" NPT on 2", 2 1/2", 3 1/2"
Black Steel Case, U-Clamp panel mount
Bronze Tube, Brass Socket
Plastic Lens Standard
Accuracy: 3-2-3%
104D-Front Mount
Dial Sizes: 1 1/2", 2", 2 1/2", 3 1/2"
Connections: 1/8" NPT on 1 1/2", & 2", 1/4" NPT on 2", 2 1/2", 3 1/2"
Black Steel Case, Front flanged panel mount
Bronze Tube, Brass Socket
Plastic Lens Standard
Accuracy: 3-2-3%
